TTC Iron vs. PH Studio Jacaranda
An in-depth look at the TTC Iron and the PH Studio Jacaranda switches—which one is the best fit for you?
Overview
When it comes to choosing a linear switch for your mechanical keyboard, both the TTC Iron and the PH Studio Jacaranda offer distinctive qualities that cater to varied typing preferences. The TTC Iron, known for its clacky sound signature and light actuation, delivers a smooth and enjoyable typing experience, making it an appealing option for both enthusiasts and casual users looking for a combination of precision and auditory satisfaction. In contrast, the Jacaranda, with its gentle 43.5g bottom-out force and unique extended 22mm spring, elevates the typing experience with a delightful bounce, providing crisp feedback while maintaining comfort during prolonged use. Both switches cater to those who appreciate a clacky auditory profile, but they diverge in tactile feel and responsiveness, making the choice between them an exciting yet challenging decision. However, let's dive in a bit deeper beyond generalities so you can best decide on the best switch for you.
By the numbers
Technical specifications
Actuation force
41g
Actuation force
39g
Bottom-out force
50g
Bottom-out force
45g
Pre-travel
1.40 mm
Pre-travel
2.00 mm
Total travel
3.80 mm
Total travel
3.50 mm
Factory lubed
Yes
Factory lubed
Yes
Stem construction
Partial box
Stem construction
Standard
Stem material
POM
Stem material
POM
Top housing material
POM
Top housing material
Polycarbonate
Bottom housing material
POM
Bottom housing material
Nylon
Mount type
Plate (3-pin)
Mount type
PCB (5-pin)
Spring
22mm single-stage spring
Spring
Single stage lengthened 22mm spring
Housing materials
The TTC Iron and the PH Studio Jacaranda both utilize distinct materials in their switch housings that significantly influence the auditory experience during use. The TTC Iron employs a POM top housing, which is known for producing a deeper and more muted sound profile, creating an overall smooth auditory experience. In contrast, the Jacaranda utilizes a polycarbonate top housing, which contributes to a sharper, higher-pitched, and crisper sound. This difference in sound quality is primarily attributed to the material properties; while POM allows for a softer and more rounded sound, polycarbonate’s stiffness enhances clarity and resonates more distinctly. Users aiming for a richer auditory feel might prefer the Iron, while those looking for a brighter and more vibrant sound may gravitate toward the Jacaranda.
When examining the bottom housings, the TTC Iron continues with a POM construction, yielding a similarly muted sound profile that harmonizes with its top housing. Conversely, the Jacaranda employs a nylon bottom housing, a classic material that generates a deeper and fuller sound due to its softer nature, which absorbs more sound than the harder POM plastic. This difference in bottom housing not only affects the auditory characteristics when the key is bottomed out but also borrows some qualities from the overall sound signature of the switch. While both homes contribute uniquely to the overall experience, the contrasting materials in the bottom housings ensure that each switch type epitomizes distinct sound characteristics.
In summary, although the TTC Iron and PH Studio Jacaranda utilize different materials for their top and bottom housings, the diverging sound profiles ultimately create a diverse range of tactile and auditory feedback for users. The POM components of the Iron provide a cohesive deeper sound experience, while the polycarbonate and nylon combination in the Jacaranda results in a more resounding and crisp auditory experience. Ultimately, if one were to mix and match these materials, it is possible to achieve similar results with careful consideration of which sound qualities from each housing material are being emphasized during the keypress and release actions. Both switches provide unique experiences dependent on user preference, demonstrating the remarkable versatility found within mechanical key switch design.
Weight
When comparing the TTC Iron linear switch and the PH Studio Jacaranda linear switch, both exhibit relatively light actuation and bottom out forces, making them suitable choices for users prioritizing comfort during extended typing or gaming sessions. The Iron has an actuation force of 41 grams and a bottom out force of 50 grams, while the Jacaranda is even lighter, with an actuation force of 39 grams and a bottom out force of 45 grams. This means that for users who prefer a lighter switch, the Jacaranda would provide a slightly easier typing experience than the Iron. Overall, while both switches prompt a quick response, the Jacaranda offers a marginally lighter touch, appealing to those who may be particularly sensitive to force, whereas the Iron delivers a mildly firmer feel. Both switches are designed for smooth performance, but the Jacaranda will likely engage a bit more effortlessly compared to the Iron.
Travel distance
When comparing the travel distances of the TTC Iron linear switch and the PH Studio Jacaranda linear switch, it is evident that the TTC Iron offers a travel distance of 3.8 mm, while the Jacaranda provides a slightly shorter travel distance of 3.5 mm. This indicates that the Iron switch has a longer travel distance, which may appeal to users who prefer a more substantial keypress experience, as it can provide a sense of depth and feedback when typing. On the other hand, the Jacaranda's shorter travel distance caters to those favoring quicker responsiveness, making it a potentially better choice for gamers or individuals who prioritize speed in their keystrokes. Both switches can deliver quality performance, but the preference for the longer or shorter travel distance ultimately hinges on the user's typing style and comfort level.
Price comparison
Which switch is more bang for your buck?
The TTC Iron has an MSRP of $5.40 per 10 switches. At Milktooth, we are able to pass on savings to our customers and offer the Iron for $4.30.
The PH Studio Jacaranda has an MSRP of $3.90 per 10 switches. At Milktooth, we are able to pass on savings to our customers and offer the Jacaranda for $3.30.
Here at Milktooth, we offer the best prices on switches (on average, 27% lower the competition). In addition, we offer free shipping on orders over $49.00. We also offer free returns and exchanges, so you can shop with guaranteed satisfaction.
That said, while price is an important piece of the puzzle, our opinion is that you should ultimately pick the option that most suits your unique preferences since you’ll be using these switches for years to come. In other words, finding something perfect for you is, in our view, the most important criteria.
Typing experience
When examining the sound profiles of the TTC Iron and the PH Studio Jacaranda linear switches, both are recognized for their distinct clacky sound signatures, which present a sharp and snappy auditory feedback with each keystroke. The Iron boasts a crisp, bright, and percussive quality that enhances the tactile experience of typing. Meanwhile, the Jacaranda also shares this clacky characteristic but adds an element of resonance, delivering a clean, high-pitched sound that can make the typing experience feel even more immersive. While both switches offer a satisfying auditory experience, the Jacaranda introduces a resonant quality that could appeal to those who appreciate a more pronounced sound profile.
In terms of feel, the TTC Iron strikes a balance with its easy-to-press nature and mild resistance, allowing for a comfortable and fatigue-free typing session without excessive effort. The buttery smoothness of its travel adds to this effortless feel, making each press a pleasant experience. On the other hand, the Jacaranda sets itself apart with its silky typing feel and bouncy sensation attributed to the extended 22mm spring. This unique quality enhances responsiveness and provides a delightful tactile feedback that can make typing feel even more enjoyable. While both switches prioritize comfort during extended use, the Jacaranda's bounce and smoothness may cater specifically to users who enjoy a more dynamic feel under their fingers.
Overall, both the TTC Iron and the PH Studio Jacaranda linear switches present compelling options for newcomers to mechanical keyboards. They share the appealing clacky sound signature, though the Jacaranda adds a resonant dimension that could enrich the auditory experience. When it comes to feel, the Iron emphasizes a more balanced and mild interaction, while the Jacaranda introduces an additional layer of smoothness and bounce that could elevate the overall typing pleasure. Depending on personal preference, one may gravitate towards the unique characteristics of either switch, but both are designed to offer enjoyable typing experiences that mitigate fatigue during prolonged usage.
Conclusion
To conclude, the choice between the TTC Iron linear switch and the PH Studio Jacaranda linear switch ultimately hinges on your personal preferences regarding typing experience and sound. If you are seeking a light switch that delivers a clacky, satisfying auditory feedback combined with a smooth, fatigue-free typing style, the TTC Iron would be a compelling option for your keyboard. Its pronounced sound signature and easy-to-press feel make it well-suited for both enthusiastic gaming and extended typing sessions. On the other hand, if you prioritize a uniquely bouncy typing experience with even lighter actuation and a crisp, resonant sound, you may find the Jacaranda to be more to your liking. The extended 22mm spring adds a distinctive element to each keystroke, making it ideal for users who appreciate a silky and immersive typing experience. Ultimately, consider what qualities—be it the sound profile, actuation weight, or the feel of each key press—are most important to you as you make your selection.
